Kafka入门（五）Kafka_4.0零依赖Zookeeper：Docker一键部署+可视化管理+Python实战

本文将会介绍如何使用Docker来启动最新版Kafka和可视化工具kafka-ui，并使用Python连接Kafka进行基础操作。

前言

在文章Kafka入门（一）Kafak介绍、安装与简单使用中，笔者介绍了Kafka的基本概念、使用场景以及从安装到使用的完整流程，包括命令行模式、Offset Explorer 可视化工具和 Python 脚本操作，适合初学者快速上手。

当时使用的Kafka版本为3.9.0，启动依赖于Zookeeper，且在本地系统中采用软件安装。

本文将会介绍如何使用Docker来启动最新版的Kafka服务和可视化工具kafka-ui.

Docker启动Kafka

拉取最新版Kafka的Docker镜像bitnami/kafka:latest,对应的Kafka版本为4.0.0，其服务启动已不再依赖于Zookeeper.

配置的docker-compose.yml文件如下：

version: '3.8'

networks:
  kafka-net:

services:
  kafka:
    image: bitnami/kafka:latest
    container_name: kafka
    networks:
      - kafka-net
    ports:
      - "9092:9092"
    volumes:
      - ./kafka_data:/bitnami/kafka
    environment:
      - KAFKA_KRAFT_MODE=true
      - KAFKA_CFG_NODE_ID=1
      - KAFKA_CFG_PROCESS_ROLES=broker,controller
      - KAFKA_CFG_CONTROLLER_QUORUM_VOTERS=1@kafka:9093
      - KAFKA_CFG_LISTENERS=SASL_PLAINTEXT://:9092,CONTROLLER://:9093
      - KAFKA_CFG_ADVERTISED_LISTENERS=SASL_PLAINTEXT://kafka:9092
      - KAFKA_CFG_LISTENER_SECURITY_PROTOCOL_MAP=SASL_PLAINTEXT:SASL_PLAINTEXT,CONTROLLER:PLAINTEXT
      - KAFKA_CFG_INTER_BROKER_LISTENER_NAME=SASL_PLAINTEXT
      - KAFKA_CFG_CONTROLLER_LISTENER_NAMES=CONTROLLER
      - KAFKA_CFG_SASL_ENABLED_MECHANISMS=PLAIN
      - KAFKA_CFG_SASL_MECHANISM_INTER_BROKER_PROTOCOL=PLAIN
      - ALLOW_PLAINTEXT_LISTENER=yes
      - KAFKA_CLIENT_USERS=jc
      - KAFKA_CLIENT_PASSWORDS=jckafka

  kafka-ui:
    image: provectuslabs/kafka-ui:latest
    container_name: kafka-ui
    depends_on:
      - kafka
    networks:
      - kafka-net
    ports:
      - "8090:8080"
    environment:
      - KAFKA_CLUSTERS_0_NAME=local
      - KAFKA_CLUSTERS_0_BOOTSTRAPSERVERS=kafka:9092
      - KAFKA_CLUSTERS_0_PROPERTIES_SECURITY_PROTOCOL=SASL_PLAINTEXT
      - KAFKA_CLUSTERS_0_PROPERTIES_SASL_MECHANISM=PLAIN
      - KAFKA_CLUSTERS_0_PROPERTIES_SASL_JAAS_CONFIG=org.apache.kafka.common.security.plain.PlainLoginModule required username="jc" password="jckafka";

该Kafka服务采用SASL/PLAIN认证方式。

Python操作Kafka

进入Kafka服务的Docker容器，新建school这个topic,命令如下：

kafka-topics.sh \
  --bootstrap-server localhost:9092 \
  --command-config /tmp/client.properties \
  --create \
  --topic school \
  --partitions 1 \
  --replication-factor 1

生产者代码：

from kafka import KafkaProducer

producer = KafkaProducer(bootstrap_servers='localhost:9092',
                         security_protocol='SASL_PLAINTEXT',
                         sasl_mechanism='PLAIN',
                         sasl_plain_username='jc',
                         sasl_plain_password='jckafka')
for i in range(10):
    message = f'Hello {i} from Kafka.'.encode('utf-8')
    producer.send(topic='school', value=message)
producer.close()

消费者代码：

from kafka import KafkaConsumer

consumer = KafkaConsumer(
    'school',
    bootstrap_servers='localhost:9092',
    security_protocol='SASL_PLAINTEXT',
    sasl_mechanism='PLAIN',
    sasl_plain_username='jc',
    sasl_plain_password='jckafka'
)

for message in consumer:
    print(f'Received message: {message.value.decode("utf-8")}')
